Product Description

• 25kwh 30kwh Solar For House Battery Energy Storage System With Lifepo4 280ah lithium battery

• Model	AIR10K5
  Performance
  Nominal Voltage	51.2 Vdc
  Nominal Capacity	205 Ah
  Battery Energy	10.5 kWh
  CUS	9.45 kWh
  Charge Current	120A
  Charge Power	6144 W
  Discharge Current	170A
  Discharge Power	8704 W
  Short circuit current	540 A
  Communication
  Display	SOC status indicator, LED indicator, LCD Display
  Communication	CAN, RS485, RS232
  General Specification
  Dimension (WxDxH mm)	465 x 186 x 695 mm
  Weight (kg)	83.5 kg
  Installation	Floor Stand or Wall Mount
  Working Temperature	-20°C-60°C
  Operating / Storage Humidity	<95% RH
  Max Operating Altitude	<2000m
  IP Rating	IP20
  Cell Technology	LiFePO4, Lithium Iron Phosphate
  Cycle life	6000 Cycles @ 80% DoD / 25C / 0.5Q 60% EOL
  Scalability	Max 15 batteries in parallel
  Standard Compliance (more available upon request)
  Certificates	CE, UN38.3
  Ordering and Deliverable Part
  Product ordering part	AIR 10K5 Battery (Cable / wall mount included)

• Company and factory

•





  ※ Shenzhen Rising Co., Ltd is a new energy storage company headquartered in Shenzhen, China with
  a cooperation factory located in Dongguan, China. We specialize in the research and development, and
  sales of energy storage batteries and energy storage inverters. Our products are designed to provide
  reliable and efficient energy storage solutions for residential and commercial customers.



  Exhibition


  ※EES Europe2023

  Application scenarios







  Compatible inverters
