Residential Low Voltage Hybrid Inverter GROWATT 5KW Inverter 48V SPF5000ES
Product Details:
| Place of Origin: | China |
| Brand Name: | Growatt |
| Certification: | CE,IEC,G83,CEI0-21,VDE,EN50438,CQC |
| Model Number: | SPH 3000-6000TL BL-UP |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | US$+1029-1134+piece |
| Packaging Details: | Each product is individually packaged in a carton or packaged according to your requirements. |
| Delivery Time: | 10-15workday |
| Payment Terms: | T/T |
| Supply Ability: | 10000 pieces month |
|
Detail Information |
|||
| Brand Name: | Growatt | Model Number: | SPH3000~6000 |
|---|---|---|---|
| Input Voltage: | 550V DC | Output Voltage: | 230V |
| Output Current: | 27.2A | Output Frequency: | 50Hz/60Hz |
| Output Type: | Single | Size: | 37.5*35*16cm |
| Type: | DC/AC Inverters | Inverter Efficiency: | 98.7% |
| Certificate: | CE,IEC,G83,CEI0-21,VDE,EN50438,CQC | Warranty: | 5Years/10Years |
| Weight: | 10.8kg | Rated AC Output Power: | 3-6KW |
| High Light: | GROWATT 5KW Inverter 48V SPF5000ES,Residential Low Voltage Hybrid Inverter,Low Voltage Hybrid Inverter GROWATT |
||
Product Description
Growatt Residential 48V Inverter Hybrid SPH 3000-6000TL BL-UP 3kw 4kw 5kw 6kw with 10years warranty
| Specifications | ||||||
| Datasheet | SPH3000 | SPH3600 | SPH4000 | SPH4600 | SPH5000 | SPH600 0 |
| DC input data | ||||||
| Max. recommended PV power | 6600W | 6600W | 6600W | 8000W | 8000W | 8000W |
| Start voltage | 150V | |||||
| Max. PV voltage | 550V | |||||
| PV voltage range | 120V-550V | |||||
| MPPT voltage range /nominal voltage |
150V-550V/360V | |||||
| Max. input current of tracker A/B | 12A/12A | |||||
| Number of MPP trackers / strings per MPP tracker |
2/1 | |||||
| AC Output | ||||||
| Rated AC output power | 3000W | 3680W | 4000W | 4600W | 4999W | 6000W |
| Max. AC apparent power | 3000VA | 3680VA | 4000VA | 4600VA | 5000VA | 6000VA |
| Max. output current | 16A | 16A | 22A | 22A | 22A | 27A |
| Nominal AC output voltage | 230V | |||||
| Nominal grid frequency | 50/60Hz | |||||
| Power factor at rated power | 1 | |||||
| THDI | <3% | |||||
| AC output power(Backup) | ||||||
| Max. output power | 3000W | |||||
| Rated AC output voltage | 230Vac | |||||
| Rated AC output frequency | 50/60Hz | |||||
| Automatic switchover time | <0.5S | |||||
| Battery data | ||||||
| Battery voltage range | 42~59V | |||||
| Max. charging voltage | 58V | |||||
| Max charging and discharging current |
66A | |||||
| Max charging and dis charging power |
3000W | |||||
| Battery type | lithium /Lead-acid | |||||
| Deep of discharging | 80%DOD/50%DOD | |||||
| Capacity of battery | 3~12kWh | |||||
| Efficiency | ||||||
| Max. efficiency | 97.5% | 97.5% | 97.5% | 97.6% | 97.6% | 97.7% |
| Euro European efficiency | 97.0% | 97.0% | 97.0% | 97.1% | 97.1% | 97.1% |
| MPPT efficiency | 99.5% | |||||
| Protection devices | ||||||
| DC switch | yes | |||||
| DC reverse polarity protection | yes | |||||
| Battery reverse protection | yes | |||||
| Output over current protection | yes | |||||
| Output over voltage protection | yes | |||||
| Ground fault mon itoring | yes | |||||
| Grid monitorin g | yes | |||||
| Integrated all - pole sensitive leakage |
yes | |||||
